DURADEK Standard Pultruded Grating


DURADEK is a standard pultruded grating product stocked by distributors nationwide. It is available with individual bearing bars in either 1″ or 1-1/2″ "I" shapes or a 2″ "T" shape.

DURADEK is a flame retardant product utilizing a polyester or vinyl ester resin. The bearing bars use both longitudinal (glass roving) and multidirectional (glass mat) reinforcements as well as a synthetic surfacing veil to provide unequaled corrosion resistance.



DURAGRID Custom Grating



DURAGRID custom grid and grating systems are designed to accommodate specific applications that cannot effectively be met by a standard fiberglass grating.

DURAGRID offers the customer options such as selection of bar spacing (which creates varying open space in the grating or grid), bar shape, cross-rod placement, custom fabrication, custom resin or color.



DURAGRATE Molded Fiberglass Grating


DURAGRATE molded fiberglass grating is a strong mesh grating panel that is the technical resistant flooring choice for many industrial applications. DURAGRATE panels are molded in one piece and features concave non-slip walking surface. The cost-effective panels allows for efficient on-site cutting to minimize grating waste and load bearing bars in both directions allow for use without continuous side support.

DURAGRATE molded fiberglass grating is significantly lighter in weight than metallic gratings and the high resin content (65%) provides long, virtually maintenance-free performance. A higher safety factor is achieved by designing in a higher glass content at the bottom of the grating for greater tensile strength.



DURAGRID Phenolic  Fire Integrity Composite Grating


DURAGRID Phenolic grating is a dramatic innovation for markets where fire safety is a major concern; it offers superior resistance to flame and high temperature with low emissions of smoke and toxic fumes. The nonflammable nature of phenolics enable phenolic grating to withstand higher temperatures than polyester or vinyl ester for extended periods of time without major structural damage. Combined with low thermal conductivity, this provides fire protection not available with alternate materials.

DURAGRID Phenolic grating was the first composite grating to receive U.S. Coast Guard approval. It is accepted for use in locations and applications as allowed in the U.S.C.G. Policy File Memorandum 2-98 for fire retardant grating meeting structural fire integrity Level 2(L2).
