Structural Building Panels


COMPOSOLITE Fiberglass Building Panel System


COMPOSOLITE is an advanced composite building panel system suitable for major load bearing structural applications. The system combines manufacturing simplicity with an almost unlimited number of configurations.

COMPOSOLITE is available in standard polyester (green), polyester fire retardant (gray) or vinyl ester fire retardant (beige) resin systems. The standard fire retardant resins meet the requirements of Class 1 rating of 25 or less per ASTM E-84 and the self-extinguishing requirements of ASTM D-635. The resin contains a UV inhibitor and the composite includes a surface veil on all exposed surfaces for enhanced corrosion and UV protection. Other resins and colors are available upon request.



DURASHIELD Fiberglass Foam Building Panel System


DURASHIELD is a tongue-and-groove fiberglass pultruded panel comprised of a pultruded skin over a foam core.

The pultruded fiberglass skin is available in either an isophthalic polyester or vinyl ester resin. Both resin systems are flame retardant (UL94 VO). Vinyl ester is utilized in more corrosive applications. A synthetic surfacing veil is incorporated into the skin to improve weathering, corrosion resistance and resistance to degradation from ultraviolet rays. Resistance to weathering can be further enhanced by the application of a polyurethane paint. The core material is rigid closed-cell urethane foam. The foam core provides an insulation "R" factor of 7 for the 1″ panel and 21 for the 3″ panel.

DURASHIELD panels are available in 1″ x 12″ and 3″ x 24″ sizes. The panels can be produced in any length that is practical. Typical lengths would be in the 12′ to 32′ range.
